SKU: BenQ TK800M - 4K HDR Home Cine
Categories: HOME THEATRE, PROJECTORS
Resolution |
4K UHD (3840 x 2160) |
Brightness (ANSI lumens) |
3000 ANSI Lumens |
Contrast Ratio (FOFO) |
10,000:1 |
Speaker |
5W x 1 |
Projection System |
DLP |
Resolution |
4K UHD (3840 x 2160) |
Resolution Support |
VGA (640 x 480) to 4K UHD (3840 x 2160) |
Brightness (ANSI lumens) |
3000 ANSI Lumens |
Contrast Ratio (FOFO) |
10,000:1 |
Display Color |
30 Bits (1.07 billion colors) |
Native Aspect Ratio |
Native 16:9 (5 aspect ratio selectable) |
Light Source Life | Normal 4,000 hours SmartEco 8,000 hours Eco 10,000 hours LampSave 15,000 hours |
Light Source Wattage |
240W |
Throw Ratio |
1.50 - 1.65 (100" @ 3.32 m) |
Zoom Ratio |
1.1x |
Keystone Adjustment |
1D, Vertical ± 40 degrees |
Projection Offset |
110% |
Clear Image Size (Diagonal) |
60"~200" / 300" |
Image Size |
30" ~ 300" |
Horizontal Frequency |
15K - 135KHz |
Vertical Scan Rate |
23 - 120Hz |
Color Wheel Segment |
4-Segment (RGBW) |
Rec.709 Coverage |
96% |
PC (D-Sub) |
x 1 PC In-1 (D-sub 15pin, Female) |
HDMI | x1 HDMI-1 (HDCP2.2) x1 HDMI-2 (HDCP1.4) |
USB Type A |
x1 USB Type A(1.5A power) |
USB Type mini B |
x1 USB Type mini B (Service) |
Audio in (3.5mm Mini Jack) |
x 1 Audio In (mini jack) |
Audio out (3.5mm Mini Jack) |
x1 Audio Out (mini jack) |
RS232 (DB-9pin) |
x1 RS232 In (D-sub 9pin, male) |
DC 12V Trigger (3.5mm Jack) |
x1 |
IR Receiver |
x1 (Front/Top) |
Security Bar |
Security Bar, Kensington Lock |
HDR |
Yes (HDR10, HLG) |
CinemaMaster Audio+2 |
Yes |
HDTV Compatibility |
480i, 480p, 576i, 567p, 720p, 1080i, 1080p, 2160p |
Power Supply |
VAC 100 ~ 240 (50/60Hz) |
Typical Power Consumption |
Max 385W, Normal 330W, Eco 250W |
Standby Power Consumption |
0.5W Max. at 100 ~ 240VAC |
Acoustic Noise (Typ./Eco.) |
33/29 dBA |
Operating Temperature |
0~40℃ |
Dimensions (W x H x D)(mm) |
353 x 135 x 272 (mm) |
Net Weight (Kg/ lbs) |
4.2 kg / 9.3 lbs |
Remote Control w/ Battery |
x 1 (RCV015) w/ AAA Battery x 2 |
Power Cord (by region) |
x 1 (3m) |
User Manual CD |
Yes |
Quick Start Guide |
Yes |
Warranty Card (by region) |
Yes |
