Resolution

1080p (1920x1080)

Brightness (ANSI lumens)

2200lm

Contrast Ratio (FOFO)

15000:1

Speaker

2W x 1

Projection System

DLP

Resolution

1080p (1920x1080)

Resolution Support

VGA(640 x 480) to WUXGA_RB (1920 x 1200) *RB = Reduced Blanking

Display Color

1.07 billion colors

Native Aspect Ratio

16:9

Light Source

Lamp

Light Source Wattage

210W

Light Source Life

• Normal 4500 hours
• Economic 6000 hours
• SmartEco 10000 hours‎

Throw Ratio

1.37-1.64 (100"@3m)

Zoom Ratio

1.2x

Lens

F/# =2.42 - 2.62, f = 19.0 - 22.65 mm

Keystone Adjustment

1D, Vertical +/- 40 degrees

Projection Offset

107%±5%

Clear Image Size (Diagonal)

60"-300"

Image Size

60''~ 300"‎

Horizontal Frequency

15K~102KHz

Vertical Scan Rate

23~120Hz

Picture Mode

Bright/ Vivid TV/ Cinema/ Sport/ User1/ User2 / 3D

Color Wheel Segment

RGBRGB

Color Wheel Speed

6x (50Hz), 4x (60Hz)‎

Rec.709 Coverage

96%

PC (D-Sub)

1

Component Video In

1 (Share with D-Sub)

HDMI

• HDMI-1 (1.4a/HDCP1.2)
• HDMI-2 (1.4a/HDCP1.2)

USB (Type mini B)

1 (Service)

Audio in (3.5mm Mini Jack)

1

Audio out (3.5mm Mini Jack)

1

RS232 (DB-9pin)

1

IR Receiver

1 (Front)

Security Bar

1

HDTV Compatibility

480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Video Compatibility

EDTV/ HDTV/ NTSC/ PAL/ SDTV‎/ SECAM

3D Compatibility‎

• Frame Sequential: Up to 720p 60hHz
• Frame Packing: Up to1080p 24Hz
• Side by Side: Up to 1080i/p 24Hz
• Top Bottom: Up to 1080p 60Hz

Power Supply

AC 100 to 240 V, 50/60 Hz

Typical Power Consumption

252W

Standby Power Consumption

<0.5W

Acoustic Noise (Typ./Eco.)

33/31dB ‎

Operating Temperature

0~40℃

Carton

Yes

Carry Bag

Yes

Remote Control w/ Battery

Yes

Power Cord (by region)

1 (1.8m)

User Manual CD

1 (24L)

Quick Start Guide

1 (18L)

Warranty Card (by region)

Yes

VGA(D-sub 15pin) Cable

Yes

Battery

AAA x2

Dimensions (W x H x D)(mm)

332.4 x 99 x 241.3 mm

Net Weight (Kg/ lbs )

2.56 kg (5.65 lbs)
