Dimensions

• Height: 1221mm (48.1 in)
• Width: 451mm (17.8 in)
• Depth: 600mm (23.62 in)

Net weight

100.60kg (221.8 lb)

Technical features

• Diamond tweeter
• Solid body Tweeter-on-Top
• Continuum™ cone FST
• Anti-Resonance plug
• Biomimetic Suspension
• Turbine™ Head
• Matrix™
• Aerofoil™ cone bass units
• Flowport

Description

3-way vented-box system

Drive units

• 1x ø25mm (1in) Diamond dome high-frequency
• 1x ø150mm (6in) Continuum cone FST midrange
• 2x ø250mm (10in) Aerofoil cone bass units

Frequency range

13Hz to 35kHz

Frequency response

15Hz to 28kHz (+/-3dB from reference axis)

Sensitivity

90dB (on axis at 2.83Vrms at 1m)

Harmonic distortion

• 2nd and 3rd harmonics (90dB,1m on axis)
• <1% 30Hz – 20kHz
• <0.3% 100Hz – 20kHz

Nominal impedance

8Ω (minimum 3.0Ω)

Recommended amplifier power

50W – 1000W into 8Ω on unclipped programme

Max recommended cable impedance

0.1Ω

Cabinet finishes

• Gloss Black
• White
• Satin Rosenut
• Satin Walnut

Grille finishes

• Black
• Grey
• Black
• Grey
