SKU: CP-UNR-4K4322-V2
Categories: CP PLUS, CP PLUS IP CCTV CAMERA PRICE LIST
| Processor | Quad-core embedded processor |
| Operating System | Embedded LINUX |
| Two-way Talk | 1 channel Input, 1 channel Output, RCA |
| User Interface | GUI |
| Video Output | 1 HDMI, 1 VGA |
| Video Resolution | HDMI: 3840 × 2160 , 1920 × 1080 , 1280 × 1024, 1280 × 720 VGA: 1920 × 1080 , 1280 × 1024, 1280 × 720 |
| Video Display Split | 1/4/8/9/16/25/36 |
| Channel | 32 channel |
| Motion Detection | MD Zones: 396(22×18). |
| Bandwidth Incoming | 200 |
| Video Loss | supports |
| Alarm Input | 4 Channel |
| Alarm Output | 2 Channel |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 2 SATA III Ports, up to 10TB Each |
| Trigger Events | Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
| Recording Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Backup Mode | USB Device/Network |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom |
| Max User Account | 128 users |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Ethernet | 1 RJ-45 port (10/100M/1000Mbps) |
| Interface Ports | 2 USB Ports (1 USB 3.0 , 1 USB 2.0 ) |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, SNMP, IP Search , ONVIF 2.4, SDK, CGI |
| Power Supply | DC12V/4A |
| Power Consumption | <6.9W (Without HDD) |
| Working Temp | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension | 375mm x 281.5mm x 56mm |
| Weight | 1.6kg (without HDD) |
