Key Features: Key Features: • H.265+/H.264 dual codec decoding; • Up to 8MP resolution preview and playback; • Max 80Mbps incoming bandwidth; • Support 1 SATA HDDs up to 6TB, 2 USB ports(2.0); • HDMI / VGA simultaneous video output; • Support Multi-brand network cameras; • ONVIF Version 2.4 conformance; • Two Years Warranty!
SKU: DH-NVR1108HS-S3/H
Categories: DAHUA, DAHUA IP CCTV CAMERA
Detailed Description:
Technical Specification System Main Processor Dual-core embedded processor Operating System Embedded LINUX Audio and Video IP Camera Input 4/8 Channel Two-way Talk N/A Display Interface 1 HDMI, 1 VGA Resolution 1920×1080, 1280×1024, 1280×720 Decoding Capacity 1ch@6MP 30fps, 4ch@1080P 25fps Multi-screen Display 4CH: 1/4 8CH: 1/4/8/9 OSD Camera title, Time, Camera lock, Motion detection, Recording Recording Compression H.265+/H.264+ Resolution 6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc. Record Rate 40Mbps Bit Rate 16Kbps ~ 20Mbps Per Channel Record Mode Manual, Schedule(Regular(Continuous), MD, Stop Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec Video Detection and Alarm Trigger Events Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips Video Detection Motion Detection, MD Zones: 396 (22 × 18), and Tampering Alarm input N/A Relay Output N/A Playback and Backup Sync Playback 4CH: 1/4 8CH: 1/4/9 Search Mode Time /Date, MD and Exact Search (accurate to second) Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom Backup Mode USB Device/Network Third-party Support Third-party Support Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more Network Interface 1 RJ-45 port (10/100Mbps) Network Function HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P Optical Fiber Interface N/A Max. User Access 128 users Smart Phone iPhone, iPad, Android Interoperability ONVIF ,SDK, CGI Conformant Storage Internal HDD 1 SATA III Port, up to 4TB capacity for each HDD HDD Mode Single eSATA N/A Auxiliary Interface USB 2 ports (2 Rear USB2.0) RS232 N/A RS485 N/A Electrical Power Supply Single, DC12V/1.5A Power Consumption <2.57W (without HDD) Environmental Operating Conditions -10°C ~ +45°C (+14°F ~ +113°F), 86 ~ 106kpa Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH Construction Dimensions(W×D×H) Cooper 1U, 197mm×196.6mm×41.5mm (7.76" x 7.74" x 1.63") Net Weight 1.15 kg (2.54 lb) (without HDD) Gross Weight 1.65kg(3.64 lb)(without HDD)
