The cabinet construction of the OBERON 1 is composed from high-density CNC machined MDF board - dressed in carefully selected high-grade vinyl. The very rigid construction of the OBERON 1 cabinet is due to solid bracings across the inside of the cabinet for reinforcement. This improves the stiffness and practically eliminates resonance within the cabinet. We have optimised the timing by fitting the speakers with acoustic damping material internally along the sides, top and bottom. This creates a more direct contact between woofer and bass port. The audible result is a more precise bass and increased ‘attack’ in the midrange. The bass ports are placed on the rear of the OBERON 1, optimising room integration by utilising the wall for improved bass performance. Above the bass port, we have integrated a key hole for on-wall mouting. With the OBERON range, we introduce a brand new front grille design. The new rounded front grille adds a lighter and more contemporary visual look to the
SKU: Dali Oberon 1 - Bookshelf Spea
Categories: HOME THEATRE, SPEAKERS, Bookshelf Speakers
Product series | OBERON |
Frequency Range (+/-3 dB) [Hz] | 51 - 26,000 |
Sensitivity (2,83 V/1 m) [dB] | 86 |
Nominal Impedance [ohms] | 6 |
Maximum SPL [dB] | 106 |
Recommended Amplifier Power [W] | 25 - 100 |
Crossover Frequency [Hz] | 2,800 |
Crossover Principle | 2-way |
High frequency driver, Quantity | 1 x 29 mm |
High frequency driver, Diaphragm type | Soft Textile Dome |
Low frequency driver, Quantity | 1 X 5.25" |
Low frequency driver, Diaphragm type | Wood Fibre Cone |
Enclosure type | Bass Reflex |
Bass Reflex Tuning Frequency [Hz] | 50 |
Connection Input | Single Wire |
Recommended Placement | Shelf or stand |
Recommended Distance From Wall [cm] | Jan-50 |
Dimensions With Base (HxWxD) [mm] | 274 x 162 x 234 |
Weight [kg] | 4.2 |
Accessories Included |
|
