Channels

• 9.2
• Object-Based Configuration: 5.1.4
• Object-Based Configuration: 7.1.2
• With External Amplifier: 11.2

Power Output per Channel

• 2-Channel Driven: 125 W at 8 Ohms / 20 Hz to 20 kHz / 0.05% THD, 165 W at 6 Ohms / 1 kHz / 0.7% THD
• 1-Channel Driven: 200 W at 6 Ohms / 1 kHz / 1% THD, 235 W at 6 Ohms / 1 kHz / 10% THD

Frequency Response

10 Hz to 100 kHz +1/-3 dB (Direct Mode)

Speaker Impedance

4 to 16 Ohms

DTS Compatibility

DTS-HD Master Audio, DTS:X

Dolby Compatibility

Dolby Atmos, Dolby Pro Logic IIz, Dolby TrueHD

Auro 3D Support

Yes

Upmixing Technology

Dolby Surround, DTS Neural:X, DTS Virtual:X, Dolby Atmos Height Virtualization Technology

Supported File Formats

AAC, ALAC, DSD, FLAC, MP3, WAV, WMA

HDR Compatibility

HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma

Pass-Through Support

8K60p 4:4:4 (3D, BT.2020)

Upscaling

8K

GUI

Yes

Rear A/V Inputs

• 7 x HDMI
• 2 x 3RCA Component
• 3 x RCA Composite
• 2 x Optical TOSLINK
• 2 x Digital Coaxial
• 5 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw

Rear A/V Outputs

• 3 x HDMI
• 1 x 3RCA Component
• 2 x RCA Composite
• 2 x RCA Subwoofer
• 1 x 11-Channel RCA Pre-Out
• 1 x Stereo RCA Zone 2 Pre-Out
• 1 x Stereo RCA Zone 3 Pre-Out

Front I/O

• 1 x HDMI Input
• 1 x USB Type-A Input
• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x 1/8" / 3.5 mm Setup Mic Input

Other Rear I/O

• 2 x Bluetooth/Wi-Fi Antenna Terminal Input
• 1 x AM Antenna Terminal Input
• 1 x FM Antenna Terminal Input
• 1 x RJ45 (Ethernet)
• 1 x DE-9 (RS-232C)
• 2 x 1/8" / 3.5 mm (12 V Trigger) Output
• 1 x 1/8" / 3.5 mm (IR) Input
• 1 x 1/8" / 3.5 mm (IR) Output

Speaker Connectors

11 x Binding Post Pairs

HDCP Support

Version 2.3

Audio Return Channel (ARC)

Yes, eARC

HDMI CEC

Yes

Input Impedance

47 Kilohms

Input Sensitivity

200 mV

Signal to Noise Ratio

102 dB (Direct Mode / IHF-A)

Wireless Audio Protocols

AirPlay 2, HEOS

Virtual Assistant Support

Amazon Alexa, Apple Siri, Google Assistant, Josh.ai

AC Input Power

230 VAC, 50 Hz

Power Consumption

• Active: 710 W
• No Sound (ECO Off): 110 W
• No Sound (ECO On): 65 W
• Network Standby: 3.5 W
• CEC Standby: 0.5 W
• Standby: 0.1 W

Dimensions (W x H x D)

• 17.1 x 9.3 x 15.3" / 43.4 x 23.6 x 38.9 cm (Antenna Up)
• 17.1 x 6.6 x 15.3" / 43.4 x 16.8 x 38.9 cm (Antenna Down)
• 17.1 x 6.6 x 14.9" / 43.4 x 16.8 x 37.8 cm (Antenna Removed)

Weight

30.2 lb / 13.7 kg
