Channels

• 11.2
• Object-Based Configuration: 7.1.4
• Object-Based Configuration: 9.1.2
• With External Amplifier: 13.2

Power Output per Channel

• 2-Channel Driven: 140 W at 8 Ohms / 20 Hz to 20 kHz / 0.05% THD, 175 W at 6 Ohms / 1 kHz / 0.7% THD
• 1-Channel Driven: 205 W at 6 Ohms / 1 kHz / 1% THD

Frequency Response

10 Hz to 100 kHz +1/-3 dB (Direct Mode)

Speaker Impedance

4 to 16 Ohms

DTS Compatibility

DTS-HD Master Audio, DTS:X

Dolby Compatibility

Dolby Atmos, Dolby Pro Logic IIz, Dolby TrueHD

Auro 3D Support

Yes

Upmixing Technology

Dolby Surround, DTS Neural:X, DTS Virtual:X, Dolby Atmos Height Virtualization Technology

Supported File Formats

AAC, ALAC, DSD, FLAC, MP3, WAV, WMA

HDR Compatibility

HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma

Pass-Through Support

8K60p 4:4:4 (3D, BT.2020)

Upscaling

8K

GUI

Yes

Rear A/V Inputs

• 7 x HDMI
• 2 x 3RCA Component
• 4 x RCA Composite
• 2 x Optical TOSLINK
• 2 x Digital Coaxial
• 6 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw

Rear A/V Outputs

• 3 x HDMI
• 1 x 3RCA Component
• 2 x RCA Composite
• 2 x RCA Subwoofer
• 1 x 13-Channel RCA Pre-Out
• 1 x Stereo RCA Zone 2 Pre-Out
• 1 x Stereo RCA Zone 3 Pre-Out

Front I/O

• 1 x HDMI Input
• 1 x USB Type-A Input
• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x 1/8" / 3.5 mm Setup Mic Input

Other Rear I/O

• 2 x Bluetooth/Wi-Fi Antenna Terminal Input
• 1 x RJ45 (Ethernet)
• 1 x DE-9 (RS-232C)
• 2 x 1/8" / 3.5 mm (12 V Trigger) Output
• 1 x 1/8" / 3.5 mm (IR) Input
• 1 x 1/8" / 3.5 mm (IR) Output

Speaker Connectors

13 x Binding Post Pairs

HDCP Support

Version 2.3

Audio Return Channel (ARC)

Yes, eARC

HDMI CEC

Yes

Input Sensitivity

200 mV

Signal to Noise Ratio

100 dB (Direct Mode / IHF-A)

Wireless Audio Protocols

AirPlay 2, HEOS

Virtual Assistant Support

Amazon Alexa, Apple Siri, Google Assistant, Josh.ai

Tuner Type

Radio Frequencies

AC Input Power

230 VAC, 50 Hz

Power Consumption

• Active: 750 W
• No Sound (ECO Off): 110 W
• No Sound (ECO On): 65 W
• Network Standby: 3.5 W
• CEC Standby: 0.5 W
• Standby: 0.1 W

Dimensions (W x H x D)

• 17.1 x 9.3 x 15.3" / 43.4 x 23.6 x 38.9 cm (Antenna Up)
• 17.1 x 6.6 x 15.3" / 43.4 x 16.8 x 38.9 cm (Antenna Down)
• 17.1 x 6.6 x 14.9" / 43.4 x 16.8 x 37.8 cm (Antenna Removed)

Weight

32 lb / 14.51 kg
