Channels

7.2

Power Output

• 75 W @ 8 Ohms, 20 Hz to 20 kHz, 0.08% THD per Channel, 2 Channels Driven
• 110 W @ 6 Ohms, 1 kHz, 0.7% THD per Channel, 2 Channels Driven
• 165 W @ 6 Ohms, 1 kHz, 10% THD, 1 Channel Driven

Speaker Impedance

4 to 16 Ohms

Audio Decoding

• Dolby: Dolby Atmos, Dolby TrueHD, Dolby Surround
• DTS: DTS:X, DTS Neural:X, DTS HD Master

Files Supported

MP3, WMA, AAC, FLAC, ALAC, and WAV

Tuner Type

FM/AM

Reception Frequencies

FM: 87.5 to 107.9 MHz

AM: 520 to 1710 kHz

Pass-Through

4K, HDR, eARC, CEC, 3D

HDCP Compliance

2.3

Wi-Fi/Bluetooth

Yes

Inputs

• 6 x HDMI (1 Front)
• 2 x RCA Composite Video
• 3 x Stereo RCA (1 Phono with Ground Screw)
• 2 x Optical TOSLINK
• 1 x Digital Coaxial

Outputs

• 1 x HDMI
• 1 x RCA Composite Video
• 2 x Subwoofer Pre-Out
• 1 x 1/4" / 6.35 mm Headphone (Front)

Other Ports

• 1 x USB Type-A (Front)
• 1 x 1/8" / 3.5 mm Setup Mic (Front)
• 1 x AM Antenna
• 1 x FM Antenna
• 1 x RJ45 Ethernet LAN

Speaker Connectors

7 x Binding Post Pairs

Dimensions (W x H x D)

• 17.1 x 6 x 13.3" / 43.4 x 15.1 x 33.9 cm with Antennas Horizontal
• 17.1 x 8.5 x 13.3" / 43.4 x 21.5 x 33.9 cm with Antennas Vertical

Weight

19 lb / 8.6 kg
