Door Station/System Parameters
Operation System
Embedded Linux operation system
Operation Mode
Single-button
Door Station/Video Parameters
Main stream: 1920 × 1080p, 720p
Night Vision
Low illumination IR supplement mode:3 m
Field Of View
Horizontal: 129° Vertical: 75°
Video Compression Standard
H.264
Main stream: 1080p@30fps, 720p@25fps
Anti-Flicker Frequency
50 Hz, 60 Hz
Door Station/Audio Parameters
Audio Input
Built-in omnidirectional microphone
Audio Output
Built-in loudspeaker
Audio Quality
Noise suppression and echo cancellation
Audio Compression Standard
G.711 U
Audio Compression Rate
64 Kbps
Audio Intercom
Two-way audio communication
Door Station/Network Parameters
Network Protocol
TCP/IP, RSTP
Wired Network
10/100 Mbps Ethernet
Door Station/Device Interfaces
Working Temperature
-40° C to +53° C(-40° F to 127.4° F)
Working Humidity
10% to 95%
Dimension
138 mm × 65 mm × 27 mm
Installation
Surface mounting
IEEE802.3af, standard PoE
Indoor Station/System Parameters
Operation System
Embedded RTOS operation system
Indoor Station/Display Parameters
Display Screen
7-inch TFT LCD
Display Resolution
1024 × 600
Operation Method
Capactive touch
Indoor Station/Audio Parameters
Audio Input
Build-in omnidirectonal microphone
Audio Output
Built-in loudspeaker
Audio Quality
Noise suppression and echo cancellation
Audio Compression Standard
G.711U, G.711A
Audio Compression Rate
64 Kbps
Indoor Station/Network Parameters
Wired Network
10/100 Mbps self-adaptive
Protocol
TCP/IP, SIP, RTSP
Indoor Station/Device Interfaces
Network Interface
RJ45, standard PoE for power supply
Power Supply
12 VDC or standard PoE
Working Temperature
-10 °C to 50 °C (-14 °F to 122 °F)
Working Humidity
0% to 90%
Dimensions (W × H × D)
200 mm × 140 mm × 15.1 mm (7.87" × 5.51" × 0.59")
Installation
Wall mounting
355 g (without packaging)
