DIMENSION (H X W X D)

240 x 155 x 180 mm (9.5 x 6.1 x 7.1in.)

WEIGHT

3.6kg (7.9lbs)

WI-FI NETWORK STANDARD & FREQUENCY BAND

• Dual-band 2.4GHz/5GHz
• IEEE 802.11a/b/g/n

DRIVER UNITS

Uni-Q driver array:

• HF: 19mm (0.75in.) aluminium dome
• LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone

INPUTS

• 2.4GHz/5GHz Dual-band Wi-Fi network
• Bluetooth 4.0 with aptX® codec
• USB Type B
• TOSLINK Optical
• RCA Analog Line Level Input
• 10/100 Mbps RJ45 Ethernet (For network and service)

OUTPUTS

• Subwoofer Output
• 5V2A DC Output

AMPLIFIER OUTPUT POWER

• LF: 70W
• HF: 30W

BLUETOOTH RANGE & MEMORY

10m
8 devices

BLUETOOTH FREQUENCY

2.402GHz - 2.48GHz

BLUETOOTH POWER

2.5mW (Bluetooth Class 2 Device)

RESOLUTION

Support up to 192kHz/24bit
Depending on source resolution

MASTER AND SLAVE SPEAKER CONNECTION

• Wireless: Propriety 2.4GHz
• Wired: RJ45 Ethernet
  Depending on connection settings

MAXIMUM OUTPUT (SPL)

102dB

POWER INPUT

100 – 240VAC 50/60Hz

WIRELESS CONNECTIVITY

TIDAL

FREQUENCY RANGE

Frequency Range (-6dB)
Measured at 85dB/1m
49Hz - 47kHz (More bass extension)
52Hz - 47kHz (Standard)
55Hz - 47kHz (Less bass extension)
Depending on speaker settings

FREQUENCY RESPONSE

Frequency Response (±3dB)
Measured at 85dB/1m
54Hz - 28kHz (More bass extension)
59Hz - 28kHz (Standard)
69Hz - 28kHz (Less bass extension)
Depending on speaker settings

THIRD PARTY SUPPORT

Mounting inserts for supporting wall mount
Supports 3rd party remote programme
Supports IP Control
