No. 25 marks a new standard in cabinet execution, both for its physical beauty and the manner in which it manages the critical backwave propagating from the rear surface of the massive 15″ carbon fibre piston at its heart. The shape of No. 25 is designed to disturb and cancel much of the incredible force created by the inward stroke as No. 25 reloads for your music or film’s next set of demands. It is necessary to keep this backwave as silent as possible, while allowing the driver to “breathe” without compressing dynamics. The curvilinear cabinet walls deflect, diffuse and dissipate these waves into smaller cross plane waves. Minimizing rear waves that eventually emerge as comb filtering — noise that cancels the primary bass — is what creates clear, purposeful bass that strides into a room with tremendous energy and clarity.
Comprised of 30mm thick (about 1 1/8″) Australian MDF, transected by hardwood spars that break up common mode resonances within the top surface of the cabinet and down its sidewalls, bracing is not unlike the spars in a ship’s hull. Some may view this as excessive, but these are the lengths our design team goes to to deliver the finest subwoofer extant, fully fitting of the title No. 25.
SKU: REL Acoustics No. 25 - Active
Categories: HOME THEATRE, SPEAKERS, Subwoofers
Type | Closed box, front-firing driver |
Active Driver Size & Material | 15 in., 380mm long-throw, carbon fibre cone with inverted carbon fibre dust cap |
Passiver Radiator Size & Material | N/A |
Low Frequency Extention | -6dB at 14 Hz |
Input Connectors | High level Neutrik Speakon, Low Level stereo RCA, LFE RCA, LFE XLR |
Output Connectors | High Level, Low Level RCA, Balanced XLR, Daisy Chain Outputs |
Power Output | 1,000 watts (RMS) Ultra High-Current Power Supply |
Amplifier Type | NextGen3 Class D |
Wireless Capability | Longbow (Optional), Zero Compression, Individual discrete D/A and A/D Encoders |
Fully Electronic Set Safe | Yes |
D.C Fault | Yes |
Output Short | Yes |
Mains Input Voltage | 220-240 volts, 110-120 volts for certain markets |
Fuses | 7 Amp semi delay 230 volts operation, 15 Amp semi delay 115 volts operation |
Dimensions (W X H X D) | 29 x 21.3 x 30 in. (736.5 x 540 x 762 mm) |
Weight | 76Kg |
Mains Lead | Yes |
Neutrik Speakon | Yes (10 Meters Nominal) |
Interconnect | N/A |
Users Manual | Yes |
