Height

• Cutout dimensions (dia.) 9.6" (24.4 cm)
• Square grille finished Height 10.7" (27.2 cm)

Width

Square grille finished Width 10.7" (27.2 cm)

Depth

Mounting depth 5.2" (13.2 cm)

Weight

1.4Kg

Features

Includes both round and square zero-bezel magnetic grilles • Round grille finished dimension (dia.) 10.7" (27.2 cm)

High Frequency Driver Components

1" aluminum dome swiveling high-output tweeter with wave

Low Frequency Extension

High Frequency Extension 3-position HF level control / Low Frequency Extension LF boundary compensation

Low Frequency Driver Components

• 8" Micro-Ceramic Composite (MCC) Cone
• Cast-Aluminum Frame High-Output Woofer

Mounting

• C-2 fastening mechanism
• Compatible with wall material thickness range 0.5" – 2.0" (1.3 cm – 5.0 cm)

Recommended Amplifier Power

10 - 150 Watts RMS
