DISPLAY DISPLAY SYSTEM SXRD panel, projection system DISPLAY RESOLUTION Computer signal input : Maximum display resolution: 1920 x 1080 dots (HDMI Input only) / Video signal input : 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, The following items are available for HDMI input only. 1080/60p, 1080/50p, 1080/24p LIGHT SOURCE High-pressure mercury lamp, 215 W type GENERAL FEATURES EFFECTIVE IMAGER SIZE 0.61 in x 3 EFFECTIVE PIXELS 6,220,800 (1920 x 1080 x 3) pixels PROJECTION LENS SHIFT Manual, Vertical: +/- 71%, Horizontal: +/- 25% SCREEN SIZE 40" to 300" (1,016 mm to 7,624 mm) HARDWARE PROJECTION LENS ZOOM / FOCUS Manual (Approx. x1.6) / Manual INTERFACE INPUT AND OUTPUT TERMINALS HDMI (2 INPUTS) – Digital RGB/Y Pb/Cb Pr/Cr, IR IN – Minijack, USB – DC 5 V, Max. 500 mA, REMOTE – RS-232C, D-sub 9-pin (female) OPERATING CONDITIONS OPERATING TEMPERATURE / HUMIDITY 5°C to 35°C (41°F to 95°F)/35% to 85% (no condensation) STORAGE TEMPERATURE / HUMIDITY -20°C to +60°C (-4°F to +140°F)/10% to 90% (no condensation) POWER ACOUSTIC NOISE 22 dB POWER REQUIREMENT AC 100 V to 240 V, 3.1 A to 1.3 A, 50/60 Hz POWER CONSUMPTION MAX 310 W VIDEO FEATURES LIGHT OUTPUT 1800 lm (Lamp mode: High)* COLOR LIGHT OUTPUT 1800 lm (Lamp mode: High)* ECO AND ENERGY SAVING POWER CONSUMPTION (STANDBY MODE) 0.4 W STANDBY MODE ACTIVATED After about 10 Minutes
